Castors wheels

HEAVY DUTY PLATE MOUNTED TWIN WHEEL CASTOR C/W BROWN POLYURETHANE TYRE/BLACK NYLON WHEEL 800-1500KG

Heavy duty fabricated black painted steel frame with double wheel configuration in swivel and fixed patterns.

Find the right option
  • Heavy duty plate mounted twin wheel castor with brown polyurethane tyre and black nylon wheel
1 1

Technical guidanceExpert support for the right solution

Samples availableGet the right part before you commit

UK & European sourcingAlternatives beyond the catalogue

Trade enquiries welcomeFrom one-off parts to ongoing supply

Read full product description

Heavy duty fabricated black painted steel frame with double wheel configuration in swivel and fixed patterns.

Swivel also available with trailing wheel brake.

Sealed swivel head with grease nipple.

Brown polyurethane tyre/black nylon wheel with roller or ball bearing axle.

FIND THE RIGHT COMPONENT

Available product options.

Search by size, dimensions or specification, select a matching product and add it to your quotation basket.

QUOTE ONLY · NO PAYMENT

Available options

Choose a matching part to review its specifications

30 options
Part numberSize / technical detailOther specificationAction
C125/2KFBXPN Fixed / 125mm / Brown polyurethane/black nylon | 45 x 2 | 175 | 175x110 (12) | 800 | 121/105x80/59 (12) | Roller | 127 —
C125/2KFBXPN Fixed / 125mm / Brown polyurethane/black nylon | 45 x 2 | 175 | 175x110 (12) | 800 | 121/105x80/59 (12) | Roller | 144 —
C125/2KFBXPN Fixed / 125mm / Brown polyurethane/black nylon | 45 x 2 | 175 | 175x110 (12) | 800 | 121/105x80/59 (12) | Roller | 167 —
C125/2KFXPNBJ Fixed / 125mm / Brown polyurethane/black nylon | 45 x 2 | 175 | 175x110 (12) | 800 | 121/105x80/59 (12) | Ball journal | 127 —
C125/2KFXPNBJ Fixed / 125mm / Brown polyurethane/black nylon | 45 x 2 | 175 | 175x110 (12) | 800 | 121/105x80/59 (12) | Ball journal | 144 —
C125/2KFXPNBJ Fixed / 125mm / Brown polyurethane/black nylon | 45 x 2 | 175 | 175x110 (12) | 800 | 121/105x80/59 (12) | Ball journal | 167 —
C125/2KXPNB Swivel / 125mm / Brown polyurethane/black nylon | 45 x 2 | 175 | 150x110 (12) | 800 | 121/105x80/59 (12) | Roller | 127 —
C125/2KXPNBBR Swivel/wheel brake / 125mm / Brown polyurethane/black nylon | 45 x 2 | 175 | 150x110 (12) | 800 | 121/105x80/59 (12) | Roller | 127 —
C125/2KXPNBJ Swivel / 125mm / Brown polyurethane/black nylon | 45 x 2 | 175 | 150x110 (12) | 800 | 121/105x80/59 (12) | Ball journal | 127 —
C125/2KXPNJBBR Swivel/wheel brake / 125mm / Brown polyurethane/black nylon | 45 x 2 | 175 | 150x110 (12) | 800 | 121/105x80/59 (12) | Ball journal | 127 —
C150/2KFBXPN Fixed / 150mm / Brown polyurethane/black nylon | 50 x 2 | 200 | 175x110 (12) | 1200 | 121/105x80/59 (12) | Roller | 127 —
C150/2KFBXPN Fixed / 150mm / Brown polyurethane/black nylon | 50 x 2 | 200 | 175x110 (12) | 1200 | 121/105x80/59 (12) | Roller | 144 —
C150/2KFBXPN Fixed / 150mm / Brown polyurethane/black nylon | 50 x 2 | 200 | 175x110 (12) | 1200 | 121/105x80/59 (12) | Roller | 167 —
C150/2KFXPNBJ Fixed / 150mm / Brown polyurethane/black nylon | 50 x 2 | 200 | 175x110 (12) | 1200 | 121/105x80/59 (12) | Ball journal | 127 —
C150/2KFXPNBJ Fixed / 150mm / Brown polyurethane/black nylon | 50 x 2 | 200 | 175x110 (12) | 1200 | 121/105x80/59 (12) | Ball journal | 144 —
C150/2KFXPNBJ Fixed / 150mm / Brown polyurethane/black nylon | 50 x 2 | 200 | 175x110 (12) | 1200 | 121/105x80/59 (12) | Ball journal | 167 —
C150/2KXPNB Swivel / 150mm / Brown polyurethane/black nylon | 50 x 2 | 200 | 150x110 (12) | 1200 | 121/105x80/59 (12) | Roller | 144 —
C150/2KXPNBBR Swivel/wheel brake / 150mm / Brown polyurethane/black nylon | 50 x 2 | 200 | 150x110 (12) | 1200 | 121/105x80/59 (12) | Roller | 144 —
C150/2KXPNBJ Swivel / 150mm / Brown polyurethane/black nylon | 50 x 2 | 200 | 150x110 (12) | 1200 | 121/105x80/59 (12) | Ball journal | 144 —
C150/2KXPNJBBR Swivel/wheel brake / 150mm / Brown polyurethane/black nylon | 50 x 2 | 200 | 150x110 (12) | 1200 | 121/105x80/59 (12) | Ball journal | 144 —
C200/2KFBXPN Fixed / 200mm / Brown polyurethane/black nylon | 50 x 2 | 250 | 175x110 (12) | 1500 | 121/105x80/59 (12) | Roller | 127 —
C200/2KFBXPN Fixed / 200mm / Brown polyurethane/black nylon | 50 x 2 | 250 | 175x110 (12) | 1500 | 121/105x80/59 (12) | Roller | 144 —
C200/2KFBXPN Fixed / 200mm / Brown polyurethane/black nylon | 50 x 2 | 250 | 175x110 (12) | 1500 | 121/105x80/59 (12) | Roller | 167 —
C200/2KFXPNBJ Fixed / 200mm / Brown polyurethane/black nylon | 50 x 2 | 250 | 175x110 (12) | 1500 | 121/105x80/59 (12) | Ball journal | 127 —
C200/2KFXPNBJ Fixed / 200mm / Brown polyurethane/black nylon | 50 x 2 | 250 | 175x110 (12) | 1500 | 121/105x80/59 (12) | Ball journal | 144 —
C200/2KFXPNBJ Fixed / 200mm / Brown polyurethane/black nylon | 50 x 2 | 250 | 175x110 (12) | 1500 | 121/105x80/59 (12) | Ball journal | 167 —
C200/2KXPNB Swivel / 200mm / Brown polyurethane/black nylon | 50 x 2 | 250 | 150x110 (12) | 1500 | 121/105x80/59 (12) | Roller | 167 —
C200/2KXPNBBR Swivel/wheel brake / 200mm / Brown polyurethane/black nylon | 50 x 2 | 250 | 150x110 (12) | 1500 | 121/105x80/59 (12) | Roller | 167 —
C200/2KXPNBJ Swivel / 200mm / Brown polyurethane/black nylon | 50 x 2 | 250 | 150x110 (12) | 1500 | 121/105x80/59 (12) | Ball journal | 167 —
C200/2KXPNJBBR Swivel/wheel brake / 200mm / Brown polyurethane/black nylon | 50 x 2 | 250 | 150x110 (12) | 1500 | 121/105x80/59 (12) | Ball journal | 167 —

Select an option to view its full specifications and choose a quantity for your quote.

Your selected product

HEAVY DUTY PLATE MOUNTED TWIN WHEEL CASTOR C/W BROWN POLYURETHANE TYRE/BLACK NYLON WHEEL 800-1500KG
C125/2KFBXPN

Choose a part number and quantity to request a quotation. No online payment is taken.

How does requesting a quote work?
  1. Find the size and product code you need from table below.
  2. Enter product code and quantities required
  3. Click Add To Quote
  4. Repeat on any other product pages as needed.
  5. Once done, submit your quote to our sales team who will be in touch within 1 hour.

Alternatively feel free to call us now on 01279 656189 for an immediate response!

View full details
01 · START HERE

Check the dimensions. Find your part number.

Use the full specification table below to identify the correct size and part number. Then return to Available product options above to select that exact part and request a quote.

Select your part & request a quote

Full technical specifications compare sizes & part numbers

Find your part in the table below, then select the matching option above to request a quote.

ALL SPECIFICATIONS VISIBLE

Check each column heading for the relevant measurements and product details. ↔ Swipe sideways to see every column.

TECHNICAL DETAILS

Product specifications.

Find part numbers and compare available options
SKU Type Wheel Dia Wheel Type Tread Width O Height Plate Size Load Cap kg Bolthole Spacing Bearing Swivel Radius
C125/2KFBXPN Fixed 125mm Brown polyurethane/black nylon 45 x 2 175 175x110 (12) 800 121/105x80/59 (12) Roller 127
C125/2KFBXPN Fixed 125mm Brown polyurethane/black nylon 45 x 2 175 175x110 (12) 800 121/105x80/59 (12) Roller 144
C125/2KFBXPN Fixed 125mm Brown polyurethane/black nylon 45 x 2 175 175x110 (12) 800 121/105x80/59 (12) Roller 167
C125/2KFXPNBJ Fixed 125mm Brown polyurethane/black nylon 45 x 2 175 175x110 (12) 800 121/105x80/59 (12) Ball journal 127
C125/2KFXPNBJ Fixed 125mm Brown polyurethane/black nylon 45 x 2 175 175x110 (12) 800 121/105x80/59 (12) Ball journal 144
C125/2KFXPNBJ Fixed 125mm Brown polyurethane/black nylon 45 x 2 175 175x110 (12) 800 121/105x80/59 (12) Ball journal 167
C125/2KXPNB Swivel 125mm Brown polyurethane/black nylon 45 x 2 175 150x110 (12) 800 121/105x80/59 (12) Roller 127
C125/2KXPNBBR Swivel/wheel brake 125mm Brown polyurethane/black nylon 45 x 2 175 150x110 (12) 800 121/105x80/59 (12) Roller 127
C125/2KXPNBJ Swivel 125mm Brown polyurethane/black nylon 45 x 2 175 150x110 (12) 800 121/105x80/59 (12) Ball journal 127
C125/2KXPNJBBR Swivel/wheel brake 125mm Brown polyurethane/black nylon 45 x 2 175 150x110 (12) 800 121/105x80/59 (12) Ball journal 127
C150/2KFBXPN Fixed 150mm Brown polyurethane/black nylon 50 x 2 200 175x110 (12) 1200 121/105x80/59 (12) Roller 127
C150/2KFBXPN Fixed 150mm Brown polyurethane/black nylon 50 x 2 200 175x110 (12) 1200 121/105x80/59 (12) Roller 144
C150/2KFBXPN Fixed 150mm Brown polyurethane/black nylon 50 x 2 200 175x110 (12) 1200 121/105x80/59 (12) Roller 167
C150/2KFXPNBJ Fixed 150mm Brown polyurethane/black nylon 50 x 2 200 175x110 (12) 1200 121/105x80/59 (12) Ball journal 127
C150/2KFXPNBJ Fixed 150mm Brown polyurethane/black nylon 50 x 2 200 175x110 (12) 1200 121/105x80/59 (12) Ball journal 144
C150/2KFXPNBJ Fixed 150mm Brown polyurethane/black nylon 50 x 2 200 175x110 (12) 1200 121/105x80/59 (12) Ball journal 167
C150/2KXPNB Swivel 150mm Brown polyurethane/black nylon 50 x 2 200 150x110 (12) 1200 121/105x80/59 (12) Roller 144
C150/2KXPNBBR Swivel/wheel brake 150mm Brown polyurethane/black nylon 50 x 2 200 150x110 (12) 1200 121/105x80/59 (12) Roller 144
C150/2KXPNBJ Swivel 150mm Brown polyurethane/black nylon 50 x 2 200 150x110 (12) 1200 121/105x80/59 (12) Ball journal 144
C150/2KXPNJBBR Swivel/wheel brake 150mm Brown polyurethane/black nylon 50 x 2 200 150x110 (12) 1200 121/105x80/59 (12) Ball journal 144
C200/2KFBXPN Fixed 200mm Brown polyurethane/black nylon 50 x 2 250 175x110 (12) 1500 121/105x80/59 (12) Roller 127
C200/2KFBXPN Fixed 200mm Brown polyurethane/black nylon 50 x 2 250 175x110 (12) 1500 121/105x80/59 (12) Roller 144
C200/2KFBXPN Fixed 200mm Brown polyurethane/black nylon 50 x 2 250 175x110 (12) 1500 121/105x80/59 (12) Roller 167
C200/2KFXPNBJ Fixed 200mm Brown polyurethane/black nylon 50 x 2 250 175x110 (12) 1500 121/105x80/59 (12) Ball journal 127
C200/2KFXPNBJ Fixed 200mm Brown polyurethane/black nylon 50 x 2 250 175x110 (12) 1500 121/105x80/59 (12) Ball journal 144
C200/2KFXPNBJ Fixed 200mm Brown polyurethane/black nylon 50 x 2 250 175x110 (12) 1500 121/105x80/59 (12) Ball journal 167
C200/2KXPNB Swivel 200mm Brown polyurethane/black nylon 50 x 2 250 150x110 (12) 1500 121/105x80/59 (12) Roller 167
C200/2KXPNBBR Swivel/wheel brake 200mm Brown polyurethane/black nylon 50 x 2 250 150x110 (12) 1500 121/105x80/59 (12) Roller 167
C200/2KXPNBJ Swivel 200mm Brown polyurethane/black nylon 50 x 2 250 150x110 (12) 1500 121/105x80/59 (12) Ball journal 167
C200/2KXPNJBBR Swivel/wheel brake 200mm Brown polyurethane/black nylon 50 x 2 250 150x110 (12) 1500 121/105x80/59 (12) Ball journal 167
