4 LOBE THERMOPLASTIC HANDKNOB

four-winged star knob is another long-standing, classic shape from our extensive range of hand knobs.

Find the right option
  • 4 lobe thermoplastic handknob with zinc plated steel stud for clamping and locking applications
1 1

Technical guidanceExpert support for the right solution

Samples availableGet the right part before you commit

UK & European sourcingAlternatives beyond the catalogue

Trade enquiries welcomeFrom one-off parts to ongoing supply

Read full product description

four-winged star knob is another long-standing, classic shape from our extensive range of hand knobs.

These star knobs are designed for a comfortable three finger and thumb grip.

The star shape is optimised for clamping and locking, as commonly required on photographic tripods, lighting stands and point-of-sale furniture.

The high impact resistant thermoplastic knob and zinc plated steel threaded male stud make for a strong, low weight and durable combination.

FIND THE RIGHT COMPONENT

Available product options.

Search by size, dimensions or specification, select a matching product and add it to your quotation basket.

QUOTE ONLY · NO PAYMENT

Available options

Choose a matching part to review its specifications

20 options
Part numberSize / technical detailOther specificationAction
HL4/25/04010R Nylon / Zinc steel / 25 | 17 | 12 | 10 | 7 | M4 | 10 | 10 —
HL4/28/06010R Nylon / Zinc steel / 28 | 11 | 11 | 6 | 17 | M6 | 10 | 10 —
HL4/28/06BR Nylon GF / Brass / 28 | 11 | 11 | 6 | 17 | M6 | n/a (female) | 10 —
HL4/40/06/P/R Polypropylene / Zinc / 40 | 12 | 15 | 8 | 20 | M6 | n/a (female) | 10 —
HL4/40/06015R Nylon / Zinc steel / 40 | 12 | 15 | 8 | 20 | M6 | 15 | 10 —
HL4/40/06020/P/R Polypropylene / Zinc steel / 40 | 12 | 15 | 8 | 20 | M6 | 20 | 10 —
HL4/40/06035/P/R Polypropylene / Zinc steel / 40 | 12 | 15 | 8 | 20 | M6 | 35 | 10 —
HL4/40/06BR Nylon GF / Brass / 40 | 12 | 15 | 8 | 20 | M6 | n/a (female) | 10 —
HL4/40/08/P/R Polypropylene / Zinc / 40 | 12 | 15 | 8 | 20 | M8 | n/a (female) | 10 —
HL4/40/08015/P/R Polypropylene / Zinc steel / 40 | 12 | 15 | 8 | 20 | M8 | 15 | 10 —
HL4/40/08020/P/R Polypropylene / Zinc steel / 40 | 12 | 15 | 8 | 20 | M8 | 20 | 10 —
HL4/40/08025/P/R Polypropylene / Zinc steel / 40 | 12 | 15 | 8 | 20 | M8 | 25 | 10 —
HL4/40/08035/P/R Polypropylene / Zinc steel / 40 | 12 | 15 | 8 | 20 | M8 | 35 | 10 —
HL4/40/08BR Nylon GF / Brass / 40 | 12 | 15 | 8 | 20 | M8 | n/a (female) | 10 —
HL4/50/08040R Nylon / Zinc steel / 50 | 15 | 15 | 9 | 24 | M8 | 40 | 10 —
HL4/60/08/P/R Polypropylene / Zinc / 60 | 18 | 19 | 12 | 30 | M8 | n/a (female) | 10 —
HL4/60/08020/P/R Polypropylene / Zinc steel / 60 | 18 | 19 | 12 | 30 | M8 | 20 | 10 —
HL4/60/08040/P/R Polypropylene / Zinc steel / 60 | 18 | 19 | 12 | 30 | M8 | 40 | 10 —
HL4/60/10040R Nylon / Zinc steel / 60 | 18 | 19 | 12 | 30 | M10 | 40 | 10 —
HL4/60/10BR Nylon GF / Brass / 60 | 18 | 19 | 12 | 30 | M10 | n/a (female) | 10 —

Select an option to view its full specifications and choose a quantity for your quote.

Your selected product

4 LOBE THERMOPLASTIC HANDKNOB
HL4/25/04010R

Choose a part number and quantity to request a quotation. No online payment is taken.

How does requesting a quote work?
  1. Find the size and product code you need from table below.
  2. Enter product code and quantities required
  3. Click Add To Quote
  4. Repeat on any other product pages as needed.
  5. Once done, submit your quote to our sales team who will be in touch within 1 hour.

Alternatively feel free to call us now on 01279 656189 for an immediate response!

View full details
Choose by specification: filter the options above, compare the full table below, and select any matching part number. Both views stay in sync.Ask our technical team →
Full technical specifications — select a part numberReal product dimensions and technical details from Indifit's catalogue
TECHNICAL DETAILS

Product specifications.

Find part numbers and compare available options
SKU Knob Material Thread Material A B C D E Thread Size Thread Length Pack Qty
HL4/25/04010R Nylon Zinc steel 25 17 12 10 7 M4 10 10
HL4/28/06010R Nylon Zinc steel 28 11 11 6 17 M6 10 10
HL4/28/06BR Nylon GF Brass 28 11 11 6 17 M6 n/a (female) 10
HL4/40/06/P/R Polypropylene Zinc 40 12 15 8 20 M6 n/a (female) 10
HL4/40/06015R Nylon Zinc steel 40 12 15 8 20 M6 15 10
HL4/40/06020/P/R Polypropylene Zinc steel 40 12 15 8 20 M6 20 10
HL4/40/06035/P/R Polypropylene Zinc steel 40 12 15 8 20 M6 35 10
HL4/40/06BR Nylon GF Brass 40 12 15 8 20 M6 n/a (female) 10
HL4/40/08/P/R Polypropylene Zinc 40 12 15 8 20 M8 n/a (female) 10
HL4/40/08015/P/R Polypropylene Zinc steel 40 12 15 8 20 M8 15 10
HL4/40/08020/P/R Polypropylene Zinc steel 40 12 15 8 20 M8 20 10
HL4/40/08025/P/R Polypropylene Zinc steel 40 12 15 8 20 M8 25 10
HL4/40/08035/P/R Polypropylene Zinc steel 40 12 15 8 20 M8 35 10
HL4/40/08BR Nylon GF Brass 40 12 15 8 20 M8 n/a (female) 10
HL4/50/08040R Nylon Zinc steel 50 15 15 9 24 M8 40 10
HL4/60/08/P/R Polypropylene Zinc 60 18 19 12 30 M8 n/a (female) 10
HL4/60/08020/P/R Polypropylene Zinc steel 60 18 19 12 30 M8 20 10
HL4/60/08040/P/R Polypropylene Zinc steel 60 18 19 12 30 M8 40 10
HL4/60/10040R Nylon Zinc steel 60 18 19 12 30 M10 40 10
HL4/60/10BR Nylon GF Brass 60 18 19 12 30 M10 n/a (female) 10
