Read full product description
similar to ‘POP’ rivet.
Multi-grip rivets offer a greater material grip range to standard rivets.
Potentially one size of multigrip rivet will cover the same size range of that of 2 or 3 sizes of standard rivets. Ideal for stores inventory reduction. It is also helpful for the end-user as saves the need of changing rivet sizes for different applications and are ideal for applications to material of inconsistent thickness such as fibreglass or resin type material.
Also available in steel and stainless steel material choice (please contact the sales office for details).
Please note: the size range shown in the listed table is a selection of the most popular fasteners we sell. However, the size range we can supply is too vast to be listed here, so if the size or specification you require is not shown, please call the sales office and we will endeavour to supply to your requirement.
Available product options.
Search by size, dimensions or specification, select a matching product and add it to your quotation basket.
Your selected product
How does requesting a quote work?
- Find the size and product code you need from table below.
- Enter product code and quantities required
- Click Add To Quote
- Repeat on any other product pages as needed.
- Once done, submit your quote to our sales team who will be in touch within 1 hour.
Alternatively feel free to call us now on 01279 656189 for an immediate response!
Check the dimensions. Find your part number.
Use the full specification table below to identify the correct size and part number. Then return to Available product options above to select that exact part and request a quote.
Full technical specifications compare sizes & part numbers
Find your part in the table below, then select the matching option above to request a quote.
Check each column heading for the relevant measurements and product details. ↔ Swipe sideways to see every column.
Product specifications.
| SKU | Pack Qty | Size | Head dia | Head type | Body material | Grip range (mm) | Pin material |
|---|---|---|---|---|---|---|---|
| ARMG3208 | 1000 | 3.2 x 8 | 6.2 | Dome | Aluminium | 0.5-5.0 | Steel zinc |
| ARMG3210 | 1000 | 3.2 x 10 | 6.2 | Dome | Aluminium | 1.5-6.5 | Steel zinc |
| ARMG3211 | 1000 | 3.2 x 11 | 6.2 | Dome | Aluminium | 4.0-8.0 | Steel zinc |
| ARMG4007 | 1000 | 4.0 x 7 | 8.2 | Dome | Aluminium | 0.5-3.5 | Steel zinc |
| ARMG4010 | 1000 | 4.0 x 9.5 | 8.2 | Dome | Aluminium | 1.0-4.0 | Steel zinc |
| ARMG4011 | 1000 | 4.0 x 11 | 8.2 | Dome | Aluminium | 2.0-6.0 | Steel zinc |
| ARMG4013 | 1000 | 4.0 x 12.5 | 8.2 | Dome | Aluminium | 4.0-9.0 | Steel zinc |
| ARMG4016 | 1000 | 4.0 x 16.5 | 8.2 | Dome | Aluminium | 6.0-13.0 | Steel zinc |
| ARMG4811 | 1000 | 4.8 x 10.5 | 10 | Dome | Aluminium | 1.5-6.5 | Steel zinc |
| ARMG4815 | 1000 | 4.8 x 15 | 10 | Dome | Aluminium | 4.5-11.0 | Steel zinc |
| ARMG4816 | 1000 | 4.8 x 16.5 | 10 | Dome | Aluminium | 6.5-12.5 | Steel zinc |
| ARMG4820 | 1000 | 4.8 x 19.5 | 10 | Dome | Aluminium | 8.5-14.5 | Steel zinc |
| ARMG4824 | 1000 | 4.8 x 24.5 | 10 | Dome | Aluminium | 12.5-20.0 | Steel zinc |
| ARMG6412 | 1000 | 6.4 x 12.0 | 13 | Dome | Aluminium | 1.0-6.0 | Steel zinc |
| ARMG6415 | 1000 | 6.4 x 15.0 | 13 | Dome | Aluminium | 4.0-9.0 | Steel zinc |
| ARMG6418 | 1000 | 6.4 x 18.0 | 13 | Dome | Aluminium | 6.0-12.0 | Steel zinc |
| ARMGC3210 | 1000 | 3.2 x 9.5 | 5.8 | Csk | Aluminium | 1.5-6.0 | Steel zinc |
| ARMGC4011 | 1000 | 4.0 x 11.0 | 7.3 | Csk | Aluminium | 2.0-8.0 | Steel zinc |
| ARMGC4812 | 1000 | 4.8 x 12.0 | 8.8 | Csk | Aluminium | 2.0-7.5 | Steel zinc |
| ARMGC4816 | 1000 | 4.8 x 16.0 | 8.8 | Csk | Aluminium | 6.0-12.0 | Steel zinc |
| ARMGLF3208 | 1000 | 3.2 x 8.0 | 9.5 | Flange | Aluminium | 0.5-5.0 | Steel zinc |
| ARMGLF4013 | 1000 | 4.0 x 13.0 | 12 | Flange | Aluminium | 3.0-9.0 | Steel zinc |
| ARMGLF4016 | 1000 | 4.0 x 16.0 | 12 | Flange | Aluminium | 6.0-13.0 | Steel zinc |
| ARMGLF4811 | 1000 | 4.8 x 10.5 | 16 | Flange | Aluminium | 1.5-6.0 | Steel zinc |
| ARMGLF4817 | 1000 | 4.8 x 17.0 | 16 | Flange | Aluminium | 6.0-12.5 | Steel zinc |
| ARMGLF4825 | 1000 | 4.8 x 25.0 | 16 | Flange | Aluminium | 12.0-19.5 | Steel zinc |
Found the correct part number? Select it from the available options above and add it to your quote list.
