What is a flange head in the context of threaded rivet nuts?

A flange head is the top hat-shaped flange that provides a larger bearing surface, ensuring secure and even load distribution when installing the threaded rivet nut.

How does the flange head design benefit the installation of rivet nuts in sheet metal?

The flange head offers a quick and easy installation process, providing stability and preventing the nut from pulling through the material, especially in sheet metal applications.

Are flange head rivet nuts suitable for front-side installation only?

Yes, flange head rivet nuts are designed for front-side application, making them ideal when rear access is limited or not available, simplifying installation.

Can I order flange head rivet nuts in custom sizes or specifications?

Absolutely, we offer a wide range of sizes beyond the listed options. Please contact our sales office with your specific requirements, and we will do our best to supply them.

What materials are available for flange head rivet nuts, and how do I choose the right one?

Flange head rivet nuts are available in various materials, such as steel and stainless steel. Choose the material based on your application's strength, corrosion resistance, and environmental conditions for optimal performance.

1 1

FLANGE HEAD CLOSED END THREADED RIVET INSERT NUTS

Name: FLANGE HEAD CLOSED END THREADED RIVET INSERT NUTS
Brand: Indifit
SKU: AFTTCC04
Availability: InStock

FLANGE HEAD CLOSED END THREADED RIVET INSERT NUTS

Female blind threaded tubular body with ‘top hat’ shaped flange head. Very quick and easy way to create threaded bushes in sheet metal, tubes or similar material.

Very easy product to apply and the nuts are ideal for application from front side only (no need for rear access).

Please note: the size range shown in the listed table is a selection of the most popular fasteners we sell. However, the size range we can supply is too vast to be listed here, so if the size or specification you require is not shown, please call the sales office and we will endeavour to supply to your requirement.

How to Request a Quote

Find the size and product code you need from table below.
Enter product code and quantities required
Click Add To Quote
Repeat on any other product pages as needed.
Once done, submit your quote to our sales team who will be in touch within 1 hour.

Alternatively feel free to call us now on 01279 656189 for an immediate response!

View full details

SKU	Material	Thread Size	Finish	Pack Qty	Head dia	Hole size	Material grip range	Body flute length	Head Thickness
AFTTCC04	Steel	M4	Zinc	500	9	6	0.3-3.0	15.5	1
AFTTCC05	Steel	M5	Zinc	500	10	7	0.3-3.0	18	1
AFTTCC06	Steel	M6	Zinc	500	12	9	0.3-3.0	20.5	1.5
AFTTCC08	Steel	M8	Zinc	500	15	11	0.5-3.0	25.5	1.5
