POLISHED QUICK RELEASE STAINLESS STEEL HINGE

heavy duty electrolytic polished stainless steel hinge for large doors, panels and hatches. The 304 stainless steel construction is strong, durable and has a high resistance to corrosion.

Find the right option

1 1

Technical guidanceExpert support for the right solution

Samples availableGet the right part before you commit

UK & European sourcingAlternatives beyond the catalogue

Trade enquiries welcomeFrom one-off parts to ongoing supply

Read full product description

heavy duty electrolytic polished stainless steel hinge for large doors, panels and hatches. The 304 stainless steel construction is strong, durable and has a high resistance to corrosion.

This hinge features a removable central pin to allow the door or hatch to be quickly removed without disconnecting the hinge leaf. Mounting is with countersunk screws or bolts.

FIND THE RIGHT COMPONENT

Available product options.

Search by size, dimensions or specification, select a matching product and add it to your quotation basket.

QUOTE ONLY · NO PAYMENT

Available options

Choose a matching part to review its specifications

2 options

Part number	Size / technical detail	Other specification	Action
EHX23451	Stainless / 82 / 184 \| 45 \| 60 \| 92 \| 20 \| Polished \| 6 \| 1	—
EHQ13451	Stainless / 82 / 92 \| 45 \| 60 \| - \| 20 \| Polished \| 6 \| 2	—

Select an option to view its full specifications and choose a quantity for your quote.

Your selected product

POLISHED QUICK RELEASE STAINLESS STEEL HINGE

EHX23451

Selected part number

Choose a part number and quantity to request a quotation. No online payment is taken.

How does requesting a quote work?

Find the size and product code you need from table below.
Enter product code and quantities required
Click Add To Quote
Repeat on any other product pages as needed.
Once done, submit your quote to our sales team who will be in touch within 1 hour.

Alternatively feel free to call us now on 01279 656189 for an immediate response!

View full details

Choose by specification: filter the options above, compare the full table below, and select any matching part number. Both views stay in sync.Ask our technical team →

Full technical specifications — select a part numberReal product dimensions and technical details from Indifit's catalogue

TECHNICAL DETAILS

Product specifications.

Find part numbers and compare available options

SKU	Material	A	B	C	D	E	F	Finish	Square Bore size	Image
EHX23451	Stainless	82	184	45	60	92	20	Polished	6	1
EHQ13451	Stainless	82	92	45	60	-	20	Polished	6	2
