What are the main benefits of using a HEXAGON SERRATED FLANGE fastener?

The HEXAGON SERRATED FLANGE fastener provides a secure grip with its serrated flange face, reducing the need for additional washers and preventing loosening due to vibration. Its high tensile Grade 8.8 steel ensures durability and strength for heavy-duty applications.

Is the HEXAGON SERRATED FLANGE fastener suitable for outdoor or corrosive environments?

Yes, the fastener is made of zinc-plated high tensile steel, offering good corrosion resistance, making it suitable for outdoor and mildly corrosive environments. For more extreme conditions, additional coating options are available upon request.

Can I get custom sizes or specifications for the HEXAGON SERRATED FLANGE fasteners?

Absolutely. While we list our most popular sizes, our product range is extensive. Please contact our sales office with your specific requirements, and we will do our best to provide a custom solution that fits your needs.

How do I ensure I choose the correct size of the HEXAGON SERRATED FLANGE fastener?

To select the correct size, measure the diameter and thread length needed for your application and refer to our size chart. If you're unsure, our sales team can assist in selecting the appropriate fastener for your project.

What maintenance or care is recommended for the HEXAGON SERRATED FLANGE fasteners?

These fasteners require minimal maintenance; cleaning with a damp cloth and occasional inspection for corrosion or damage is sufficient. If exposed to harsh conditions, consider applying an additional protective coating to extend their lifespan.

1 1

HEXAGON SERRATED FLANGE FACED HIGH TENSILE GRADE 8.8 STEEL ZINC FULLY THREADED SETSCREW

Grade 8.8 high tensile steel zinc fully threaded fastener with serrated flange face for extra grip.

Please note : the size range shown in the table we have listed is a selection of the most popular fasteners we sell. However, the product range we can supply is infinite so if the size or specification you require is not shown then please call the sales office and we will endeavour to supply to your requirement.

How to Request a Quote

Find the size and product code you need from table below.
Enter product code and quantities required
Click Add To Quote
Repeat on any other product pages as needed.
Once done, submit your quote to our sales team who will be in touch within 1 hour.

Alternatively feel free to call us now on 01279 656189 for an immediate response!

View full details

SKU	Material	Finish	Size	Box qty	head a/f	Head height	Flange dia	Thread pitch
AHSFM05012Z	High tensile steel	Zinc	M5 x 12	1000	10	6.6	14.2	1
AHSFM05016Z	High tensile steel	Zinc	M5 x 16	1000	10	6.6	14.2	1
AHSFM05020Z	High tensile steel	Zinc	M5 x 20	1000	10	6.6	14.2	1
AHSFM05025Z	High tensile steel	Zinc	M5 x 25	1000	10	6.6	14.2	1
AHSFM05030Z	High tensile steel	Zinc	M5 x 30	1000	10	6.6	14.2	1
AHSFM05035Z	High tensile steel	Zinc	M5 x 35	1000	10	6.6	14.2	1
AHSFM05040Z	High tensile steel	Zinc	M5 x 40	1000	10	6.6	14.2	1
AHSFM06012Z	High tensile steel	Zinc	M6 x 12	1000	10	6.6	14.2	1
AHSFM06016Z	High tensile steel	Zinc	M6 x 16	1000	10	6.6	14.2	1
AHSFM06020Z	High tensile steel	Zinc	M6 x 20	1000	10	6.6	14.2	1
AHSFM06025Z	High tensile steel	Zinc	M6 x 25	1000	10	6.6	14.2	1
AHSFM06030Z	High tensile steel	Zinc	M6 x 30	1000	10	6.6	14.2	1
AHSFM06035Z	High tensile steel	Zinc	M6 x 35	1000	10	6.6	14.2	1
AHSFM06040Z	High tensile steel	Zinc	M6 x 40	1000	10	6.6	14.2	1
AHSFM06045Z	High tensile steel	Zinc	M6 x 45	1000	10	6.6	14.2	1
AHSFM06050Z	High tensile steel	Zinc	M6 x 50	1000	10	6.6	14.2	1
AHSFM06060Z	High tensile steel	Zinc	M6 x 60	1000	10	6.6	14.2	1
AHSFM08016Z	High tensile steel	Zinc	M8 x 16	1000	13	8.1	18	1.25
AHSFM08020Z	High tensile steel	Zinc	M8 x 20	1000	13	8.1	18	1.25
AHSFM08025Z	High tensile steel	Zinc	M8 x 25	1000	13	8.1	18	1.25
AHSFM08030Z	High tensile steel	Zinc	M8 x 30	1000	13	8.1	18	1.25
AHSFM08035Z	High tensile steel	Zinc	M8 x 35	1000	13	8.1	18	1.25
AHSFM08040Z	High tensile steel	Zinc	M8 x 40	1000	13	8.1	18	1.25
AHSFM08050Z	High tensile steel	Zinc	M8 x 50	1000	13	8.1	18	1.25
AHSFM08060Z	High tensile steel	Zinc	M8 x 60	1000	13	8.1	18	1.25
AHSFM08070Z	High tensile steel	Zinc	M8 x 70	1000	13	8.1	18	1.25
AHSFM10020Z	High tensile steel	Zinc	M10 x 20	500	15	9.2	22.3	1.5
AHSFM10025Z	High tensile steel	Zinc	M10 x 25	500	15	9.2	22.3	1.5
AHSFM10030Z	High tensile steel	Zinc	M10 x 30	500	15	9.2	22.3	1.5
AHSFM10035Z	High tensile steel	Zinc	M10 x 35	500	15	9.2	22.3	1.5
AHSFM10040Z	High tensile steel	Zinc	M10 x 40	500	15	9.2	22.3	1.5
AHSFM10045Z	High tensile steel	Zinc	M10 x 45	500	15	9.2	22.3	1.5
AHSFM10050Z	High tensile steel	Zinc	M10 x 50	500	15	9.2	22.3	1.5
AHSFM12025Z	High tensile steel	Zinc	M12 x 25	500	16	11.5	26.6	1.75
AHSFM12030Z	High tensile steel	Zinc	M12 x 30	500	16	11.5	26.6	1.75
AHSFM12035Z	High tensile steel	Zinc	M12 x 35	500	16	11.5	26.6	1.75
AHSFM12040Z	High tensile steel	Zinc	M12 x 40	500	16	11.5	26.6	1.75
AHSFM12045Z	High tensile steel	Zinc	M12 x 45	500	16	11.5	26.6	1.75
AHSFM12050Z	High tensile steel	Zinc	M12 x 50	500	16	11.5	26.6	1.75
